| Led Source | TD-WS-30W (144pcs leds) |
TD-WS-340W (144pcs leds) |
TD-WS-350W (144 pcs leds) |
TD-WS-360W (144 pcs leds) | TD-WS-380W (192 pcs leds) |
TD-WS-3100W (192pcs leds) |
TD-WS-3120W (192pcs leds) | ||||
| Mono Solar Panel | 18V 40W | 18V 50W | 18V 65W | 18V 80W | 18V 100W | 18V 130W | 18V 170W | ||||
| LifePO4 Battery | 12.8V 18AH | 12.8V 24AH | 12.8V 30AH | 12.8V 36AH | 12.8V 42AH | 12.8V 54AH | 12.8V 60AH | ||||
| Color Temperature | 2700K-6500K | ||||||||||
| Brightness | 5100LM | 6800LM | 8500LM | 10200LM | 13600LM | 17000LM | |||||
| Working Time | 12-15hours, 5-7 cloudy/ rainy days | ||||||||||
| Charging Time | 6-8hours | ||||||||||
| IP Rating | IP66 | ||||||||||
| Mounting Height | 4-6m | 5-7m | 6-8m | 7-9m | 8-10m | 9-12m | 10-12m | ||||
| Space between 2 lamps | 10-20m | 15-25m | 20-30m | 20-30m | 25-35m | 30-40m | 30-40m | ||||
| Warranty | 3 years / 5 years | ||||||||||
| Package Size | Lamp: 695*300*115mm Solar panel: 610*580*80mm |
Lamp: 695*300*115mm Solar panel: 750*580*80mm |
Lamp: 695*300*115mm Solar panel: 820*580*80mm |
Lamp: 695*300*115mm Solar panel: 1090*580*80mm |
Lamp: 785*300*115mm Solar panel: 1290*580*80mm |
Lamp: 785*300*115mm Solar panel: 1130*580*80mm |
Lamp: 785*300*115mm Solar panel : 1490*580*80mm |
||||
| Gross Weight | Lamp: 4.6KG | Lamp: | 5.2KG | Lamp: 6KG Solar panel: 7.2KG |
Lamp: | 6.6KG | Lamp: 7.5KG | Lamp: 9KG | Lamp: | 9.6KG | |
| Solar panel: | 5.2KG | Solar panel: | 6.3KG | Solar panel: | 9KG | Solar panel: 11KG | Solar panel: 13.2KG | Solar panel: | 15.8KG | ||
